    UL Standard Corrugated Flexible Electrical Conduit Insulation Tensile Strength

    Ask Lasest Price
    Brand Name : HX
    Model Number : HX-LQ
    Certification : ISO9001, SGS
    Price : negotiatiable
    Payment Terms : L/C, T/T
    Supply Ability : 200000 Meter/ month
    Delivery Time : 15-20days upon 1* 20GP
    • Product Details
    • Company Profile

    UL Standard Corrugated Flexible Electrical Conduit Insulation Tensile Strength

    UL standard Liquid Tight Flexible Metal Conduit , flexible liquid tight conduit


    Liquid-tight Smooth PVC Coated Metal Conduit
    Product material:
    (inner layer) adopting hot-dipped galvanized steel band with special anticorrosion treatment ;(outer layer) adopting PVC raw material (anti-UV, anti-aging).
    Working temperature:
    -10℃ ~ +80℃,instantaneously can be +100℃,can be customized high temperature and low temperature resistant products.
    Certification:
    RoHS,CE,flame retardant certification FV-0.
    Color:
    Black,Grey
    Property:
    1,excellent waterproof ,insulation and tensile strength;
    2,PVC surface thickened layer, smooth appearance ,and with flame retardant;
    3,Square locked structure increase the tensile strength,not easily broken or deformed;
    4,internal smooth structure is very easy for the entry of wire and cable.
    Usage:
    protecting wires/cables and provide insulation and waterproof performance.
    Application:
    widely used in robots,aerospace,power generation,high-speed rail subway,railway equipment, shipbuilding,chemical industry,communication system,engineering equipment installation,industrial automation equipment,machine tool equipment,lighting equipment,electrical insulation protection system of indoor and outdoor environment of wire and cable protection.
    How to use:
    Put the wires/cables through conduit before matching the correspondent type of LNE-DPJ connectors.

    SIZEID(mm)OD(mm)Bending
    Radius (mm)
    Lenght/roll m
    MINMAXMINMAX
    1/2"15.816.220.821.38550
    3/4"20.721.126.321.610050
    1"6.226.832.733.415050
    11/4"34.735.341.442.218020
    11/2"4040.747.448.322020
    2"50.851.659.460.325020
    21/2"6363.672.17330010
    3"7878.787.988.945010
    4"101.6102.6113.2114.36005
